Features:
1. IP68 waterproof
2. Temperature: -35OC~125OC
3. Rated Current: ≤10A
4. Insulation Resistance: ≥100MΩ
5. Contact Resistance: ≤20MΩ
6. Withstand Voltage Test: 3500V
7. Plug Service Life: ≥1,000 times
8.100% conduction, no segment, short circuit, pole dislocation phenomenon.
Technical Requirements:
Cable:
1. Specification H07RN2x1.5mm2 rubble extension cable
2. Outer Diameter: OD=9.3±0.2
3. Rated Voltage: 450V/750V
4. Rated Temperature: 60OC
5. Color: Black body; Brown and Blue wire code
6. Execution Standard: VDE 0282
Appearance:
1. No damage or deformation in the body
2. Plug without shrinkage, deformation, lack of glue, overflow edge
3. Terminal is in place without deformation
Performance:
1. IP68 waterproof
2. Temperature: -35OC~125OC
3. Rated Current: ≤10A
4. Insulation Resistance: ≥100MΩ
5. Contact Resistance: ≤20MΩ
6. Withstand Voltage Test: 3500V
7. Plug Service Life: ≥1,000 times
8.100% conduction, no segment, short circuit, pole dislocation phenomenon.
Environmental Protection
1. Meet the latest RoHS requirements
