IP69K Tri-proof LED Light

Features：

• IP69K, IP67,Anti-ammonia
• PMMA IK08(Cover)+ Stainless Steel(end cap)
• Against water pressure of 100bar(1450psi) and temperature of 80°C
• System efficiency up to 130lm/W & 150lm/W option
• High CRI >80
• UGR<19 option
• Linkable options with quick connection
• Environmentally friendly, no mercury, No UV, No IR
• Wide beam angle 120°
• Energy Efficiency Grade: A+
• Quick Start instant 100% luminous flux
• Flicker Free driver
• 5 Year Warranty on complete fixture. (LED’s, Driver & Housing)
• Certificate: CE,RoHs Certified
• Surface Mount or Suspended

Description

Description

Product Brief

szAMB LED Tri-proof Light L9 are an ideal solution for food processing
and poultry lighting industry.

The IP69K is the highest level of this protection and is designed for
applications where water jets are under high pressure and high
temperature are used for specific wash-downs. This will also
include special sensitization and chemical cleaning. In some instances,
the cleaning process involves very intensive requirements for
industries such as Food & Beverage as well as the vehicle industry.

Specification

Model No.	TP2D-20W	TP4D-40W	TP5D-50W	TP5D-60W
Input Power	20W	40W	50W	60W
Dimension	552*φ75mm	1152*φ75mm	1452*φ75mm	1452*φ75mm
CCT	4000k/5000k/6000k
CRI	>80
Power Factor	>0.9
IP Grade	IP69k
Input Voltage	AC200-240V(50/60Hz)
Lumen Efficiency	130lm/w
Beam Angle	120°
Working Temp	-40°-45°
Warranty	5 years
L9	50,000H
Light Souce	SMD2835
LED Q’ty	192pcs	312pcs	400pcs	468pcs
N.W/CTN	10	16	18	18
G.W/CTN	12	18	20	20
Q’ty/CTN	9	6	6	6
Size/CTN	710270270mm	1310270270mm	1610270200mm	1610270200mm
